Nylon+Glass Fiber Water Strand Pelletizing System Twin Screw Extruder Plastic Granules Twin Screw Extruder

Product Description
Technical Data of plastic extruder machine
Nylon+Glass Fiber Water Strand Pelletizing System Twin Screw Extruder Plastic Granules Twin Screw Extruder

Model
DiameterL/DRotating speedPowerCapacityWeight
TSE-65A62.436-40500r/min716N.M180-2504000kg
TSE-65B62.436-40600r/min716N.M200-3004000kg
TSE-65C62.436-40600r/min875N.M220-3504000kg


Application
Nylon+Glass Fiber Water Strand Pelletizing System Twin Screw Extruder Plastic Granules Twin Screw Extruder

Special for waste plastic recycling, and convert to PP PE PET PS ABS PA PVC etc granules.

Special for plastic compound filling masterbatch .such as pp / pe+caco3.

Two stage machine has better performance in recycling pvc and filling masterbatch !

1.Electric control system

Frame structure control cabinet

Imported electrical elements

Imported temperature control system

Imported driving system

Interlock and multi-protection

Adopting imported PLC (OMRON or SIMES ) to achieve optimized process control.Stronger function, steady performance and much higher accuracy.

It can be also accomplished full-set link-lock protection, trouble safeguard, fault alarm cluing and so on

Operation interface on touching screen is visual and marked, which is brief and easy to use.

2.The Gearbox

New-style project of parallel three-axises driving makes the convey axis, convey chain, decelerate and the torque assignment get together, which keeo it compact, and the key bearings are imported.

The select material of drive components is dainty.Including super intension alloy cementiteing steel, cementiting and quenching, gear grinding technics, strengthening of tooth face.So they can ensure high torque, high precision and low noise.

Soakage and coerce lubrication integrate smoothly.When the hydraulic circuit is over pressed, it alarms


4.The Screw Barrel

Euro-style rectangle barrel, reflux refrigeration is optimized and disposed, which makes temperature difference in C areas smaller
According to the material and special techinics demands, the material of cylinder can use high quality nitrided steel, corrosion proof or antifriction with corresponding process
The screw material is made of high tool steel 38CrMoALA or W6Mo5Cr4V2 by special heat- treament
 Nylon+Glass Fiber Water Strand Pelletizing System Twin Screw Extruder Plastic Granules Twin Screw Extruder


FAQ

1.Q:How can we go to your factory?

R:Our factory is located in Nanjing jiangning, Jiangsu Province, China,

1) You can fly to Nanjing Airport directly.We will pick you up on Nanjing Lukou International airport;About 20 mintues to our company

2) You can fly to Shanghai Pudong International Airport then come to Nanjing by High-speed railway, then we will pick you up in the railway station.About 8 mintues to our company

All our clients, from domestic or abroad, are warmly welcome to visit us!

2.Q:Why chose us?

R:1)Quick reply.Once we received the inquiry from Alibaba, we will reply you within 24hours.

2)Quick manufacturing time.To guarantee the quality, the machine will be finished within 60days.

3) Before delivery, the machine will be tested to ensure every part is ok.

4) Wooden case package to ensure no damage during shipping.

3.Q:What is the payment?

R:1) T/T payment;2) LC;
